Deep-Dive: ANNEXA-I Biomarker Substudy — Andexanet's Therapeutic Window Is 1 Hour, and It Cuts Both Ways
ANNEXA-I Biomarker Substudy — Andexanet’s Therapeutic Window Is 1 Hour, and It Cuts Both Ways
Clinical Question (PICO)
In adults with intracranial hemorrhage associated with factor Xa (FXa) inhibitor treatment (apixaban or rivaroxaban), does andexanet alfa versus usual care, change anti-FXa activity and endogenous thrombin potential (ETP) at 1 hour — and do those biomarker changes independently predict the trial’s two competing outcomes (hematoma expansion at 12 hours and arterial thromboembolic events through 30 days)?
Bottom Line
Andexanet produced massive biomarker shifts at 1 hour: anti-FXa activity dropped from baseline by a median 98.3 ng/mL (vs 10.9 with usual care, P < 0.001), and ETP rose by a median 753.1 nmol/L·min (vs 126.6, P < 0.001). In adjusted analyses, anti-FXa reduction at 1 hour independently predicted fewer hematoma expansions (OR 0.69 per 100 ng/mL, 95% CI 0.53–0.92, P = 0.010). ETP rise at 1 hour independently predicted both fewer hematoma expansions (OR 0.94 per 100 nmol/L·min, 95% CI 0.90–0.99, P = 0.019) AND more arterial thromboembolic events (OR 1.08 per 100 nmol/L·min, 95% CI 1.00–1.16, P = 0.047). The biomarker signal is the same mediator producing both benefit and harm — and it’s concentrated in the first hour.
Design
- Trial type: Pre-specified secondary biomarker analysis embedded in the multicenter, randomized, controlled, outcome-assessor-blinded ANNEXA-I trial.
- N analyzed: 530 enrolled.
- Anti-FXa substudy: 438 with baseline values.
- ETP substudy: 328 with baseline values.
- Randomization: 1:1 (parent trial).
- Setting: 131 sites in 23 countries.
- Enrollment: June 6, 2019 – May 27, 2023.
- Mean follow-up: 30 days (for thromboembolic events); 12 hours (for hematoma expansion).
- Analysis: Wilcoxon rank-sum for between-arm biomarker change; multivariable logistic regression for hematoma expansion at 12 h (adjusted for time from symptom onset to baseline scan, baseline DBP, hematoma volume, baseline biomarker level, time from baseline scan to treatment); Cox regression for arterial thromboembolic events through 30 days (adjusted for age, baseline biomarker level, prior MI, high-dose andexanet eligibility). Natural direct/indirect effects via bootstrapping.
- Primary biomarker outcomes: 1-hour change in anti-FXa activity and 1-hour change in ETP.
Population
Inclusion Criteria
- Age ≥ 18 years.
- Acute intracranial hemorrhage within 6 hours of symptom onset.
- Receiving an oral FXa inhibitor (apixaban or rivaroxaban).
- Available baseline biomarker (anti-FXa or ETP) sample.
Exclusion Criteria
- Glasgow Coma Scale score < 7 at randomization.
- Planned surgery to evacuate hematoma within 12 hours.
- History of thrombotic event within the prior 2 weeks.
Baseline Characteristics (n = 530)
- Mean age (cohort-dependent; reported in primary trial): ~79 years.
- Sex: ~46% female.
- Intraparenchymal bleeds: ~99%.
- Median baseline hematoma volume: ~9 mL.
Interventions
- Andexanet alfa: high or low dose per FXa inhibitor and timing of last FXa dose (per FDA label / ANNEXA-I protocol).
- Usual care: predominantly 4-factor PCC (86.4% of usual-care arm).
Outcomes
Primary Biomarker Outcome (1-hour anti-FXa activity)
- Andexanet: median 8.6 ng/mL; median reduction from baseline 98.3 ng/mL.
- Usual care: median 97.5 ng/mL; median reduction 10.9 ng/mL.
- P < 0.001 — substantially greater anti-FXa reduction with andexanet.
Secondary Biomarker Outcome (1-hour ETP)
- Andexanet: median 1573.5 nmol/L·min; median increase 753.1.
- Usual care: median 874.5 nmol/L·min; median increase 126.6.
- P < 0.001 — substantially greater ETP rise with andexanet.
Mediator Analysis — Hematoma Expansion (HE) at 12 hours
- Anti-FXa reduction at 1 h (per 100 ng/mL): adjusted OR 0.69 (95% CI 0.53–0.92), P = 0.010.
- ETP increase at 1 h (per 100 nmol/L·min): adjusted OR 0.94 (95% CI 0.90–0.99), P = 0.019.
Mediator Analysis — Arterial Thromboembolic Events (30 days)
- Anti-FXa reduction at 1 h: not significantly associated with TE.
- ETP increase at 1 h (per 100 nmol/L·min): adjusted OR 1.08 (95% CI 1.00–1.16), P = 0.047.
Adverse Events / Safety
- Both biomarker effects wash out by 12 hours.
- The same mediator (ETP rise) predicts both benefit and harm — the trade-off is mechanistically inseparable.
Figures
Source: PMC PMC12180696 — str-56-1807-g001.jpg. Click image to expand.
Source: PMC PMC12180696 — str-56-1807-g002.jpg. Click image to expand.
Source: PMC PMC12180696 — str-56-1807-g006.jpg. Click image to expand.
Criticisms
- Benefit and harm share a mediator. The ETP rise that drives HE reduction also drives thrombotic events. There is no biomarker- identified subgroup where benefit is preserved without harm.
- 12-hour washout of biomarker effect. By the time the parent trial’s 30-day functional outcomes are measured, both biomarker signals have resolved. The link between biomarker effect and durable clinical benefit remains inferential.
- Heterogeneity of FXa inhibitors. Anti-FXa activity and ETP behavior differ between apixaban and rivaroxaban; the substudy does not formally test treatment-by-inhibitor interactions.
- Industry sponsorship. Funded by Portola (andexanet’s original developer) and Alexion AstraZeneca Rare Disease. The biomarker framing emphasizes mechanism over clinical outcome.
- Limited paired biomarker data. Only 255 patients had paired baseline-and-1h samples; the mediator analyses are restricted to that subset.
- Adjusted model selection. The authors adjusted for time from baseline scan to treatment, baseline DBP, hematoma volume, baseline biomarker level, prior MI, and age — but residual confounding from unmeasured variables (e.g., FXa inhibitor dose timing relative to presentation) is plausible.
Funding
Funded by Portola Pharmaceuticals (original developer of andexanet) and Alexion AstraZeneca Rare Disease (acquirer during the trial). The biomarker substudy is investigator-initiated within the parent ANNEXA-I framework. Several authors disclose AstraZeneca, Alexion, Bayer, BMS/Pfizer, Boehringer Ingelheim, and other antithrombotic manufacturer relationships.
The paper
- Authors. John W Eikelboom, Mukul Sharma, Lizhen Xu, Krister Bamberg, Jan Beyer-Westendorf, Cecilia Falkenberg, Per Ladenvall, Rohit Narayan, Robert C Penland, Peter Verhamme, Ashkan Shoamanesh.
- Title. Association of Biomarkers With Intracerebral Hematoma Expansion and Arterial Thromboembolic Events in Patients With Acute Intracranial Hemorrhage: The ANNEXA-I Biomarker Substudy.
- Journal. Stroke.
- DOI. 10.1161/STROKEAHA.124.049966
- PMCID. PMC12180696
- Registration. NCT03661528
The mechanistic paper that the ANNEXA-I trial owed us. Andexanet cuts hematoma expansion — and increases thrombotic events. The biomarker substudy says both effects share a single mediator: the endogenous thrombin potential (ETP) overshoot that peaks at 1 hour and disappears by 12 hours. That’s not just pharmacology; it’s a clock.
Deep Dive — click to expand
What this is
A pre-specified secondary analysis of the ANNEXA-I RCT (n=530) showing that andexanet’s reduction in anti-FXa activity and rise in endogenous thrombin potential at 1 hour independently predict both fewer hematoma expansions AND more arterial thromboembolic events — with both biomarker signals washed out by 12 hours. The therapeutic window for benefit-and-harm is the first hour.
1. Shadow Audit
a) The mediation is incomplete. The authors explicitly concede: “mediation analyses did not establish that the effects of andexanet on hematoma expansion were explained by effects on anti-FXa activity or ETP. These analyses were limited by lack of statistical power as reflected by the wide CIs.” That’s the load-bearing sentence — and it’s missing from the abstract’s confident framing. The headline (“biomarkers independently associated with both outcomes”) is a far cry from “the biomarkers mediate the trial effect.” This is an association paper wearing a mechanism paper’s clothes.
b) The “usual care” arm is heterogenous and 100% non-U.S. standard. “In the usual care group, 33 patients did not receive a prothrombin complex concentrate” — meaning the control arm is a mixed bag of PCC, 4F-PCC, andexanet-not-given, and probably some andexanet-ineligibles. The thrombotic excess attributed to andexanet may partly reflect that the “control” included both prothrombin concentrate AND nothing-at-all (where “nothing” has its own small pro-thrombotic fingerprint).
c) No functional outcome data are reported. The trial (and this substudy) never reports mRS at 30/90 days. Hematoma expansion is a surrogate. A 12.5 mL or 35% volume difference in the ICH that doesn’t translate to functional independence is a biomarker, not a benefit. The biomarker is the entire endpoint here.
d) Population excluded. Patients with GCS <7, planned surgical evacuation within 12h, thrombotic event within 2 weeks, or hematoma volume >60 mL were excluded. Translation: the sickest ICH patients — the ones who actually drive mortality — aren’t represented. The mean age is 79.1; 47.8% female. This is a frailer-than-average AF population, and they got FXa inhibitors, so they’re a selected survivor cohort even before trial entry.
e) Edoxaban is absent. The parent trial enrolled apixaban/rivaroxaban/edoxaban users, but the biomarker substudy restricts to apixaban + rivaroxaban only. Edoxaban’s dose-response to andexanet is materially different (high-dose regimen required), and the cleanest mechanistic story would have come from including it.
2. Inversion Engine
For the conclusion “andexanet’s harms outweigh its benefits” to be right, three things would need to flip:
a) The hematoma-expansion benefit would have to fail to translate to functional outcome. If you assume hematoma expansion is a valid surrogate (the authors do), the benefit is real. If you assume hematoma expansion in a mean-79-year-old AF cohort on FXa inhibitors is mostly a cosmetic CT finding that doesn’t change mRS at discharge — then andexanet’s entire rationale collapses. We don’t know, because mRS isn’t reported. The trial stopped at the surrogate.
b) The 1-hour ETP spike would have to be the cause of thrombosis rather than a marker of restoration-of-flow. The authors themselves note: “withdrawal of effective protection following reversal of anticoagulation” is a “mechanism that is supported by findings from the ANNEXA-4 study.” Translation: the ETP rise might not be prothrombotic per se; it might just be unmasking the underlying atrial disease that was being suppressed by the now-reversed anticoagulant. If that’s true, no amount of “more careful reversal” will reduce harm; you’ll just push hematoma expansion back.
c) PCC would have to actually work in FXa-associated ICH. The 2020 ACC pathway and most guidelines recommend PCC when andexanet is unavailable. The biomarker substudy’s quiet killing blow: “Our findings of only a minimal increase in ETP at 1 hour in the usual care arm and lack of association between the change between baseline and 12 hours in ETP and risk of hematoma expansion do not support their use for this indication.” If the field accepts that line, PCC — used in 89% of the usual-care arm — has just been demoted from “best alternative” to “plausible placebo.” A whole therapeutic category collapses.
3. Second-Order Catalyst
Within 30 days: Pharmacy committees at academic stroke centers add anti-FXa and ETP level-of-care-orders for any patient receiving andexanet. The ACC Expert Consensus pathway (Reference 5) gets a footnote — andexanet-induced ETP surge is now a labeled adverse event with monitoring recommendations.
Within 90 days: Neurocritical care fellowship curricula reframe andexanet as “1-hour-window drug with measurable biomarker signature” rather than “reversal agent.” Order sets move anti-FXa and ETP draw-time from “before-and-after” to “Q1h for 4h” — a small but real practice change.
Within 6 months: AHA/ASA’s ICH guideline committee (next cycle) and Neurocritical Care Society position both face the surrogate-versus-functional question. ANNEXA-I’s biggest gap (no mRS) gets called out. Industry-funded follow-ups (ANNEXA-I Extension, ANNEXA-I-Plus) start registering.
Within 12 months: The field splits. One camp argues the 1h ETP overshoot is the price of admission and develops “andexanet + brief anticoagulation bridge” protocols (start a DOAC at hour 12 — the exact time the biomarker normalizes). The other camp demands a head-to-head RCT against PCC powered for functional outcome, not hematoma expansion.
Last to move: Community hospitals and rural telestroke networks, who never had andexanet anyway and never had rapid ETP assays. They stay on PCC and get more evidence that their practice is mechanistically empty but pragmatically defensible.
4. Asymmetric Leverage
The single biggest claim with the most leverage: “ETP at 1 hour independently predicts hematoma expansion AND thromboembolic events in opposite directions.” If true, ETP becomes the single biomarker that maps the entire risk-benefit calculus of andexanet. You could, in principle, titrate the dose — push ETP up just enough to stop the bleed without crossing the thrombosis threshold. That’s a $500M drug-design target and a personalized-medicine play.
The single smallest claim that costs the most if wrong: “Andexanet’s benefits are explained at least in part by rapid reversal of anti-FXa activity and increase in ETP.” If the mediation analysis (which the authors admit is underpowered) turns out to be negative on replication, the entire mechanistic narrative — and with it the FDA label rationale and the 2024 NEJM publication’s mechanistic framing — collapses. You’re left with “the drug works, we don’t know why, and it causes clots.” That’s a regulatory migraine.
The asymmetric-payoff test the field should run: A randomized comparison of high-dose vs. low-dose andexanet in FXa-ICH, with ETP at 1h as the dose-titration target. If lower-dose achieves the same hematoma-expansion benefit with a flatter ETP curve and fewer thromboembolic events, the high-dose regimen is dead. AstraZeneca-funded or not, this is the natural next study and it’s almost certainly being designed right now.
5. Paradigm Destroyer
a) The mechanistic credibility of PCC for FXa-inhibitor reversal. The Discussion’s quiet poison pill — “Our findings of only a minimal increase in ETP at 1 hour in the usual care arm… do not support their use for this indication” — is the death of PCC’s claim to efficacy in this population. PCC never had RCT-level evidence for hematoma expansion as an endpoint; it had surrogate biomarker data and physiological plausibility. Both just got weaker.
b) The “andexanet is just a reversal agent” framing. The biomarker data confirm the inconvenient truth from the parent trial: andexanet is a reversal agent that overshoots. That overshoot IS the thrombotic risk. It is not a side effect to be mitigated; it is the pharmacology.
c) The implicit assumption that hematoma expansion is a clean surrogate for functional outcome. The authors never re-test that assumption because they don’t have mRS. The field has been living on that assumption for a decade. ANNEXA-I was supposed to put it to bed; instead it exposed the gap.
What it does NOT kill: the role of PCC when andexanet is unavailable; the role of 4-factor PCC in warfarin reversal (where INR-driven dosing is the target, not ETP); the broader case for andexanet over PCC in FXa-ICH (which still favors andexanet on the primary endpoint of hematoma expansion — the harms question is different).
MVP — Minimum Viable Proof
The cheapest single trial that would change this paper’s evidentiary weight:
A multicenter, biomarker-driven, dose-finding RCT of andexanet in FXa-ICH with ETP at 1 hour as the dose-titration target. Arms: (1) standard high-dose andexanet, (2) ETP-titrated andexanet (target ETP rise 400–600 nmol/L·min, below the thrombosis inflection), (3) usual care / 4F-PCC. Primary endpoint: hematoma expansion at 12h. Secondary: 30-day composite of ischemic stroke / MI / systemic embolism AND mRS at 90 days.
n ≈ 600 (200 per arm) gives 80% power to detect a 30% relative reduction in thrombotic events between standard-dose and ETP-titrated arms. Cost: ~$25M. Timeline: 3 years. Would resolve: does the ETP overshoot drive the harm? Can the benefit be preserved at lower doses? Is the entire field of andexanet dose-selection currently set too high?
A single biomarker dataset from this trial would either validate or refute the entire mechanistic claim in this substudy — and either keep andexanet at the top of the formulary or push it into a niche.
Best Combination
The single move with the highest asymmetric payoff based on the 5 frameworks:
Add an ETP-guided re-anticoagulation protocol to every center using andexanet for FXa-ICH. Begin a prophylactic-dose DOAC at hour 12 — the exact moment the biomarker substudy shows ETP no longer separates andexanet from usual care. This is a free intervention (DOACs are generic), it directly addresses the withdrawal-of-protection mechanism the authors themselves invoke (“withdrawal of effective protection following reversal of anticoagulation”), it requires no new regulatory approval, and it leverages the one robust temporal finding in this paper (the 12-hour washout) rather than the underpowered mediation claim.
Cost to test: a single-center quality-improvement cohort, n=50. Asymmetric upside: if the protocol reduces 30-day thromboembolic events by even 30%, it changes AHA/ASA guidance within a year.
Overvalue Warning
a) The mediation claim is genuinely underpowered. The authors admit this in the Discussion. Do not read “biomarkers independently associated with outcomes” as “biomarkers explain the treatment effect.” Those are different statistical claims and the paper only supports the first.
b) Surrogate endpoints. Hematoma expansion at 12h is a CT-volume surrogate. The biomarker-outcome associations are surrogate-on-surrogate. Two layers of surrogate inference compound; the field has repeatedly been burned by this (think: MISTIE, CLEAR-III).
c) The thrombotic-event count is small. “Among the 426 patients with both baseline and 1-hour anti-FXa activity results, 27 patients experienced an arterial thromboembolic event… 20 patients… 22 patients.” A 27-event endpoint in a 426-patient cohort with multiple covariates is a fragile finding. The OR 1.08 (1.00–1.16) has a lower CI that brushes 1.00 — p=0.047 is one decimal place from “not significant.”
d) Industry involvement. Four authors are AstraZeneca employees (Bamberg, Falkenberg, Ladenvall, Narayan) or hold AstraZeneca stock (Penland). The ANNEXA-I trial itself was AstraZeneca-sponsored. The discussion of ETP-as-thrombosis-mechanism benefits the drug narrative (it positions the harm as “expected pharmacology”) and the framing of PCC-as-ineffective removes the cheap alternative. Read the Discussion with that filter on.
e) Single time point dominance. The 1-hour window is the entire story. In a real-world stroke unit, “1 hour post-andexanet” is when the patient is in the scanner, not when the lab is drawing blood. The biomarker story may be biologically true but operationally inconvenient.
Bias to watch for: novelty bias on a drug whose mechanism of harm was already known from ANNEXA-4 (Reference 6/7). This isn’t a new finding; it’s a more granular measurement of a finding the field already had. The asymmetry here is mostly temporal precision, not biological surprise.
